pCIBN(deltaNLS)-pmGFP
(Plasmid #26867)

• Purpose: Expresses CIBN(1-170, -NLS)-eGFP-CaaX fusion for use in light-inducible protein interaction modules for targeting to the plasma membrane
• Depositing Lab: Chandra Tucker
• Publication: Kennedy et al Nat Methods. 2010 Dec;7(12):973-5. doi: 10.1038/nmeth.1524

Backbone

• Vector backbone: pEGFP-C1
• Backbone manufacturer: Clontech
• Backbone size w/o insert (bp): 4700
• Vector type: Mammalian Expression

Growth in Bacteria

• Bacterial Resistance(s): Kanamycin, 50 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: CIBN(deltaNLS)-pmGFP
• Alt name: CIB1
• Species: A. thaliana (mustard weed)
• Insert Size (bp): 513
• Mutation: NLS sequences mutated
• Entrez Gene: CIB1 (a.k.a. AT4G34530, T4L20.110, T4L20_110, cryptochrome-interacting basic-helix-loop-helix 1)
• Promoter: CMV
• Tag / Fusion Protein:
  • EGFP (C terminal on backbone)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: Nhe I (not destroyed)
• 3′ cloning site: Age I (not destroyed)
• 5′ sequencing primer: n/a

Resource Information

• Articles Citing this Plasmid:
  • 24 References

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry
