pJC20-Tpm4.2 (Rn)
(Plasmid #99359)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 99359 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pET3a
  • Backbone manufacturer
    Novagen
  • Backbone size w/o insert (bp) 4674
  • Total vector size (bp) 5529
  • Modifications to backbone
    T7 promoter replaced with Rhamnose inducible promoter
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Tpm4.2
  • Species
    R. norvegicus (rat)
  • Insert Size (bp)
    747
  • Entrez Gene
    Tpm4 (a.k.a. Tpm4.2, Tpm4.2cy)
  • Promoter Rhamnose

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer T7 forward
  • 3′ sequencing primer T7 term
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pJC20-Tpm4.2 (Rn) was a gift from Dan Mulvihill (Addgene plasmid # 99359 ; http://n2t.net/addgene:99359 ; RRID:Addgene_99359)
  • For your References section:

    An enhanced recombinant amino-terminal acetylation system and novel in vivo high-throughput screen for molecules affecting alpha-synuclein oligomerisation. Eastwood T, Baker K, Brooker H, Frank S, Mulvihill DP. FEBS Lett. 2017 Feb 18. doi: 10.1002/1873-3468.12597. 10.1002/1873-3468.12597 PubMed 28214355
