pJC20-Tpm4.2 (Rn)
(Plasmid
#99359)
-
PurposeBacterial expression vector containing cDNA encoding for the Rattus norvegicus tropomyosin, Tpm4.2 under the control of the pRhamnose promoter
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 99359 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepET3a
-
Backbone manufacturerNovagen
- Backbone size w/o insert (bp) 4674
- Total vector size (bp) 5529
-
Modifications to backboneT7 promoter replaced with Rhamnose inducible promoter
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameTpm4.2
-
SpeciesR. norvegicus (rat)
-
Insert Size (bp)747
-
Entrez GeneTpm4 (a.k.a. Tpm4.2, Tpm4.2cy)
- Promoter Rhamnose
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site NdeI (not destroyed)
- 3′ cloning site BamHI (not destroyed)
- 5′ sequencing primer T7 forward
- 3′ sequencing primer T7 term (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pJC20-Tpm4.2 (Rn) was a gift from Dan Mulvihill (Addgene plasmid # 99359 ; http://n2t.net/addgene:99359 ; RRID:Addgene_99359) -
For your References section:
An enhanced recombinant amino-terminal acetylation system and novel in vivo high-throughput screen for molecules affecting alpha-synuclein oligomerisation. Eastwood T, Baker K, Brooker H, Frank S, Mulvihill DP. FEBS Lett. 2017 Feb 18. doi: 10.1002/1873-3468.12597. 10.1002/1873-3468.12597 PubMed 28214355
