PurposeMammalian expression plasmid for untagged human CXCR4
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 98942 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepcDNA3.1(+)
-
Backbone manufacturerInvitrogen
- Backbone size w/o insert (bp) 5344
- Total vector size (bp) 6412
-
Vector typeMammalian Expression
-
Selectable markersNeomycin (select with G418)
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameCXCR4
-
Alt nameCD184
-
SpeciesH. sapiens (human)
-
Insert Size (bp)1068
-
MutationFull-length, wildtype
-
GenBank IDNM_003467
-
Entrez GeneCXCR4 (a.k.a. CD184, D2S201E, FB22, HM89, HSY3RR, LAP-3, LAP3, LCR1, LESTR, NPY3R, NPYR, NPYRL, NPYY3R, WHIM, WHIMS, WHIMS1)
- Promoter CMV
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site NheI (not destroyed)
- 3′ cloning site XhoI (not destroyed)
- 5′ sequencing primer T7
- 3′ sequencing primer BGH-rev (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pcDNA3-CXCR4 was a gift from Erik Procko (Addgene plasmid # 98942 ; http://n2t.net/addgene:98942 ; RRID:Addgene_98942) -
For your References section:
Mapping Interaction Sites on Human Chemokine Receptors by Deep Mutational Scanning. Heredia JD, Park J, Brubaker RJ, Szymanski SK, Gill KS, Procko E. J Immunol. 2018 Apr 20. pii: jimmunol.1800343. doi: 10.4049/jimmunol.1800343. 10.4049/jimmunol.1800343 PubMed 29678950
