VN-beta Synuclein
(Plasmid #89483)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 89483 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone size w/o insert (bp) 5941
  • Total vector size (bp) 6345
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    SNCB
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    404
  • GenBank ID
    XM_006714916
  • Entrez Gene
    SNCB
  • Promoter CMV
  • Tag / Fusion Protein
    • N-terminal part of Venus (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AflII (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer T7
  • 3′ sequencing primer bGH
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Original clone (VN-alpha-Synuclein) comes from Pamela J.McLean.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Original clone (VN-alpha Synuclein) includes already the N-terminal part of venus, and was a gift from Pamela J.McLean.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    VN-beta Synuclein was a gift from Tiago Outeiro (Addgene plasmid # 89483 ; http://n2t.net/addgene:89483 ; RRID:Addgene_89483)
  • For your References section:

    Yeast reveals similar molecular mechanisms underlying alpha- and beta-synuclein toxicity. Tenreiro S, Rosado-Ramos R, Gerhardt E, Favretto F, Magalhaes F, Popova B, Becker S, Zweckstetter M, Braus GH, Outeiro TF. Hum Mol Genet. 2016 Jan 15;25(2):275-90. doi: 10.1093/hmg/ddv470. Epub 2015 Nov 18. 10.1093/hmg/ddv470 PubMed 26586132
