pET30-2-GAPDH
(Plasmid #83910)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 83910 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pET30-2
  • Backbone size w/o insert (bp) 5647
  • Total vector size (bp) 6682
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    glyceraldehyde-3-phosphate dehydrogenase
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1035
  • GenBank ID
    NM_002046.5
  • Entrez Gene
    GAPDH (a.k.a. G3PD, GAPD, HEL-S-162eP)
  • Promoter T7
  • Tag / Fusion Protein
    • 6x His tags (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (unknown if destroyed)
  • 3′ cloning site BamHI (unknown if destroyed)
  • 5′ sequencing primer T7 Promoter
  • 3′ sequencing primer T7 Terminator
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pET30-2-GAPDH was a gift from David Sabatini (Addgene plasmid # 83910 ; http://n2t.net/addgene:83910 ; RRID:Addgene_83910)

  • For your References section:

    A PHGDH inhibitor reveals coordination of serine synthesis and one-carbon unit fate. Pacold ME, Brimacombe KR, Chan SH, Rohde JM, Lewis CA, Swier LJ, Possemato R, Chen WW, Sullivan LB, Fiske BP, Cho S, Freinkman E, Birsoy K, Abu-Remaileh M, Shaul YD, Liu CM, Zhou M, Koh MJ, Chung H, Davidson SM, Luengo A, Wang AQ, Xu X, Yasgar A, Liu L, Rai G, Westover KD, Vander Heiden MG, Shen M, Gray NS, Boxer MB, Sabatini DM. Nat Chem Biol. 2016 Jun;12(6):452-8. doi: 10.1038/nchembio.2070. Epub 2016 Apr 25. 10.1038/nchembio.2070 PubMed 27110680
