pcDNA3.1(+)-TTF-1-AD1-deletion
(Plasmid #75265)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 75265 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1(+)
  • Backbone manufacturer
    Invitrogen
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    TTF-1
  • Species
    H. sapiens (human)
  • Mutation
    AD1 (activation domain 1) deleted
  • Entrez Gene
    NKX2-1 (a.k.a. BCH, BHC, NK-2, NKX2.1, NKX2A, NMTC1, T/EBP, TEBP, TITF1, TTF-1, TTF1)
  • Tag / Fusion Protein
    • none

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Xho I (not destroyed)
  • 3′ cloning site Xho I (not destroyed)
  • 5′ sequencing primer TAA TAC GAC TCA CTA TAG G
  • 3′ sequencing primer TAG AAG GCA CAG TCG AGG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1(+)-TTF-1-AD1-deletion was a gift from David Mu (Addgene plasmid # 75265 ; http://n2t.net/addgene:75265 ; RRID:Addgene_75265)

  • For your References section:

    Occludin is a direct target of thyroid transcription factor-1 (TTF-1/NKX2-1). Runkle EA, Rice SJ, Qi J, Masser D, Antonetti DA, Winslow MM, Mu D. J Biol Chem. 2012 Aug 17;287(34):28790-801. doi: 10.1074/jbc.M112.367987. Epub 2012 Jul 2. 10.1074/jbc.M112.367987 PubMed 22761434
