Ai65(RCFL-tdT) targeting vector
(Plasmid #61577)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 61577 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    Rosa26 Targeting Vector
  • Backbone size w/o insert (bp) 2881
  • Total vector size (bp) 16295
  • Vector type
    Mouse Targeting, Cre/Lox
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    Stbl2
  • Growth instructions
    Grow in 15 microg/ml kanamycin
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    pCAG-FSF-LSL-tdTomato
  • Promoter CAG

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Sac1 (not destroyed)
  • 3′ cloning site Cla (not destroyed)
  • 5′ sequencing primer TCTTCGCTATTACGCCAGCT
  • 3′ sequencing primer AACAGCTATGACCATG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

NOTE: There are some minor discrepancies between the depositor's assembled sequence and Addgene's quality control sequence. The depositing lab has assessed these differences and states that they do no affect function.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Ai65(RCFL-tdT) targeting vector was a gift from Hongkui Zeng (Addgene plasmid # 61577 ; http://n2t.net/addgene:61577 ; RRID:Addgene_61577)

  • For your References section:

    Transgenic mice for intersectional targeting of neural sensors and effectors with high specificity and performance. Madisen L, Garner AR, Shimaoka D, Chuong AS, Klapoetke NC, Li L, van der Bourg A, Niino Y, Egolf L, Monetti C, Gu H, Mills M, Cheng A, Tasic B, Nguyen TN, Sunkin SM, Benucci A, Nagy A, Miyawaki A, Helmchen F, Empson RM, Knopfel T, Boyden ES, Reid RC, Carandini M, Zeng H. Neuron. 2015 Mar 4;85(5):942-58. doi: 10.1016/j.neuron.2015.02.022. 10.1016/j.neuron.2015.02.022 PubMed 25741722
