PX552
(Plasmid #60958)

• Purpose: pAAV-U6sgRNA(SapI)_hSyn-GFP-KASH-bGH (SpGuide acceptor). AAV plasmid for sgRNA cloning. GFP-KASH fusion facilitates FACS sorting of cells and nuclei.
• Depositing Lab: Feng Zhang
• Publication: Swiech et al Nat Biotechnol. 2014 Oct 19. doi: 10.1038/nbt.3055.

Want a viral vector made from this plasmid?

Make a packaging request and we'll get back to you.

This service is available to academics and nonprofits only.

Please log in to submit a packaging request.

• Serotype: Select serotype for details See details about
• Pricing: Select serotype and quantity $ USD for preparation of µL virus + $30 USD for plasmid.
• How this works:
  • Place a request for a quantity of 10 (1 mL), 25 (2.5 mL), or 50 (5 mL). Our all-inclusive pricing includes DNA production and QC.
  • Addgene will quickly confirm that we can produce a high-quality prep for you.
  • Track your request and place an order from within your account. Payment information must be added before we can begin processing your order.
  • Receive your prep in 6–9 weeks after the MTA is approved by your organization.
  • Learn more about our Packaged on Request Service.

Backbone

• Vector backbone: pAAV
• Backbone size w/o insert (bp): 2905
• Total vector size (bp): 5314
• Vector type: Mammalian Expression, Mouse Targeting, AAV, CRISPR

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): Stbl3
• Copy number: High Copy

Gene/Insert 1

• Gene/Insert name: U6_(SpaI)_sgRNA
• Species: Synthetic
• Insert Size (bp): 351
• Promoter: U6

Cloning Information for Gene/Insert 1

• Cloning method: Gibson Cloning
• 5′ sequencing primer: cgcgtgagggcctatttcc
• 3′ sequencing primer: gcaagtgggttttaggaccag

Gene/Insert 2

• Gene/Insert name: Syn_EGFP-KASH
• Species: Synthetic
• Insert Size (bp): 349
• Promoter: Synapsin

Cloning Information for Gene/Insert 2

• Cloning method: Gibson Cloning
• 5′ sequencing primer: ctgcgtatgagtgcaagtgggtt
• 3′ sequencing primer: ccgttggtgtaccgcagcatg

Resource Information

• Supplemental Documents:
  • PX552
  • protocol for cloning sgRNA
• Articles Citing this Plasmid:
  • 54 References

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry
