PurposeIn vivo visualization of the cytoplasm, but not the nucleus (can be used for colocalization studies)
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 36206 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepmTurquoise2-N1
- Total vector size (bp) 4778
-
Vector typeMammalian Expression
-
Selectable markersNeomycin (select with G418)
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameNES
-
Alt nameNuclear Export Sequence
-
SpeciesSynthetic
-
Insert Size (bp)42
- Promoter CMV
-
Tag
/ Fusion Protein
- mTurquoise2 (N terminal on backbone)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BsrgI (not destroyed)
- 3′ cloning site NotI (not destroyed)
- 5′ sequencing primer AGGTCTATATAAGCAGAGC
- 3′ sequencing primer TCTACAAATGTGGTATGGC (Common Sequencing Primers)
Resource Information
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pmTurquoise2-NES was a gift from Dorus Gadella (Addgene plasmid # 36206 ; http://n2t.net/addgene:36206 ; RRID:Addgene_36206) -
For your References section:
Structure-guided evolution of cyan fluorescent proteins towards a quantum yield of 93%. Goedhart J, von Stetten D, Noirclerc-Savoye M, Lelimousin M, Joosen L, Hink MA, van Weeren L, Gadella TW Jr, Royant A. Nat Commun. 2012 Mar 20;3:751. doi: 10.1038/ncomms1738. 10.1038/ncomms1738 PubMed 22434194
