pFUS_B4
(Plasmid #31021)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 31021 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCR8
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 2447

Growth in Bacteria

  • Bacterial Resistance(s)
    Spectinomycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Growth instructions
    DH10B/LB+antibiotics
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    LacZ + BsaI restriction sites
  • Insert Size (bp)
    459

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AflII (not destroyed)
  • 3′ cloning site XbaI (not destroyed)
  • 5′ sequencing primer pCR8_F1 (ttgatgcctggcagttccct)
  • 3′ sequencing primer pCR8_R1 (cgaaccgaacaggcttatgt)
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pFUS_B4 was a gift from Adam Bogdanove & Daniel Voytas (Addgene plasmid # 31021 ; http://n2t.net/addgene:31021 ; RRID:Addgene_31021)

  • For your References section:

    Efficient design and assembly of custom TALEN and other TAL effector-based constructs for DNA targeting. Cermak T, Doyle EL, Christian M, Wang L, Zhang Y, Schmidt C, Baller JA, Somia NV, Bogdanove AJ, Voytas DF. Nucleic Acids Res. 2011 Jul;39(12):e82. doi: 10.1093/nar/gkr218 10.1093/nar/gkr218 PubMed 21493687
