pcDNA3 mCerulean LIC cloning vector (6E)
(Plasmid #30128)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 30128 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA3
  • Backbone size (bp) 6145
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    None
  • Tag / Fusion Protein
    • mCerulean (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site LIC site vKoz/GFP (destroyed during cloning)
  • 3′ cloning site LIC site vKoz/GFP (destroyed during cloning)
  • 5′ sequencing primer CMV F (5'cgcaaatgggcggtaggcgtg)
  • 3′ sequencing primer GFP reverse (5'cagctcgaccaggatgggc3')
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

This is an empty LIC vector derived from pcDNA3. It adds an mCerulean gene to the C-terminus of your protein of interest.

mCerulean has a excitation max of 435 nm and an emission max of 477 nm.

To clone into this vector, add the following tags to your PCR primers:

LIC vKoz Forward tag 5’-TACTTCCAATCCAATGCCACC(ATG)

LIC vGFP Reverse tag 5’-CTCCCACTACCAATGCC

Do NOT include a stop codon with your reverse primer.

T4-treat PCR with dCTP. Linearize vector with SspI, then T4-treat with dGTP. Can verify the presence of insert by digesting with HindIII and XbaI.

For more information, please see our website:
http://qb3.berkeley.edu/qb3/macrolab/

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3 mCerulean LIC cloning vector (6E) was a gift from Scott Gradia (Addgene plasmid # 30128 ; http://n2t.net/addgene:30128 ; RRID:Addgene_30128)
