PurposeCas9-EDV production plasmid. Expresses the v2 Gag-Cas9 polypeptide (CAG promoter) and sgRNA (human U6 promoter. BsmBI cutsites for spacer insertion)
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 201914 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCAGGS
- Total vector size (bp) 11206
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameGag-Cas9 v2
- Promoter CAG
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer CTCTAGAGCCTCTGCTAACC
- 3′ sequencing primer GCCAGAAGTCAGATGCTCAAGG (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pJRH-1179 U6-reci Gag-Cas9 v2 was a gift from Jennifer Doudna (Addgene plasmid # 201914 ; http://n2t.net/addgene:201914 ; RRID:Addgene_201914) -
For your References section:
In vivo human T cell engineering with enveloped delivery vehicles. Hamilton JR, Chen E, Perez BS, Sandoval Espinoza CR, Kang MH, Trinidad M, Ngo W, Doudna JA. Nat Biotechnol. 2024 Jan 11. doi: 10.1038/s41587-023-02085-z. 10.1038/s41587-023-02085-z PubMed 38212493
