pHis-BRD4 BD1
(Plasmid #196544)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 196544 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pHis (modified pET28b)
  • Modifications to backbone
    pET28b modified Vector_TEV cleavage site inserted
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    BRD4 BD1
  • Alt name
    HUNK1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    375
  • Entrez Gene
    BRD4 (a.k.a. CAP, CDLS6, FSHRG4, HUNK1, HUNKI, MCAP)
  • Promoter T7 promoter

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer T7 promoter
  • 3′ sequencing primer T7 terminator
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pHis-BRD4 BD1 was a gift from Byung Il Lee (Addgene plasmid # 196544 ; http://n2t.net/addgene:196544 ; RRID:Addgene_196544)

  • For your References section:

    Crystal structure of [1,2,4]triazolo[4,3-b]pyridazine derivatives as BRD4 bromodomain inhibitors and structure-activity relationship study. Kim JH, Pandit N, Yoo M, Park TH, Choi JU, Park CH, Jung KY, Lee BI. Sci Rep. 2023 Jul 4;13(1):10805. doi: 10.1038/s41598-023-37527-w. 10.1038/s41598-023-37527-w PubMed 37402749
