pAAV.hSyn.iGluSnFR3.v857.PDGFR
(Plasmid #178329)

• Purpose: Fluorescent reporter for glutamate, third generation, variant 857. iGluSnFR3.v857
• Depositing Lab: Kaspar Podgorski
• Publication: Aggarwal et al Nat Methods. 2023 May 4. doi: 10.1038/s41592-023-01863-6.

Backbone

• Vector backbone: pAAV hSyn
• Backbone size w/o insert (bp): 4261
• Total vector size (bp): 6088
• Vector type: Mammalian Expression, Mouse Targeting, AAV, Cre/Lox, Synthetic Biology

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 30°C
• Growth Strain(s): NEB Stable
• Growth instructions: <8 hours
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: pAAV hSyn iGluSnFR3 v857.PDGFR
• Alt name: iGluSnFR3 v857.PDGFR
• Alt name: iGluSnFR3 556dot857.PDGFR
• Alt name: v857.PDGFR
• Species: M. musculus (mouse), R. norvegicus (rat), Synthetic
• Insert Size (bp): 1821
• Tags / Fusion Proteins:
  • IgK-chain (N terminal on insert)
  • Myc epi tag (C terminal on insert)
  • PDGFR TM Domain (C terminal on insert)

Resource Information

• Supplemental Documents:
  • pAAVgood.Syn.iGluSnFR3.v857.PDGFR.gb

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Information for AAV1 (Catalog # 178329-AAV1)

Purpose

Ready-to-use AAV1 particles produced from pAAV.hSyn.iGluSnFR3.v857.PDGFR (#178329). In addition to the viral particles, you will also receive purified pAAV.hSyn.iGluSnFR3.v857.PDGFR plasmid DNA.

Synapsin-driven, third generation glutamate sensor iGluSnFR3, variant 857. These AAV preparations are suitable purity for injection into animals.

Delivery

• Volume: 100 µL
• Titer: ≥ 7×10¹² vg/mL
• Pricing: $375 USD for preparation of 100 µL virus + $30 USD for plasmid.
• Storage: Store at -80℃. Thaw just before use and keep on ice.
• Shipment: Viral particles are shipped frozen on dry ice. Plasmid DNA (≥ 200ng) will also be included in the shipment.

Viral Production & Use

• Packaging Plasmids: encode adenoviral helper sequences and AAV rep gene, AAV1 cap gene
• Buffer: PBS + 0.001% Poloxamer 188 + 200 mM NaCl
• Serotype: AAV1
• Purification: Iodixanol gradient ultracentrifugation

Biosafety

Requestor is responsible for compliance with their institution's biosafety regulations. Lentivirus is generally considered BSL-2. AAV is generally considered BSL-1, but may require BSL-2 handling depending on the insert. Biosafety Guide

Terms and Licenses

• Academic/Nonprofit Terms:
  • Terms of Use for Viral Vectors
• Industry Terms:
  • Not Available to Industry

Viral Quality Control

Quality Control:

• Addgene ensures high quality viral vectors by optimizing and standardizing production protocols and performing rigorous quality control (QC) (see a list of our QC assays). The specific QC assays performed varies for each viral lot. To learn which specific QC assays were performed on your lot, please contact us.
• Titer: the exact titer of your sample will be reported on the tube. The titer you see listed on this page is the guaranteed minimum titer. See how titers are measured.

Visit our viral production page for more information.
