Addgene

Piggybac-TetO-hNurr1-blast
(Plasmid #176485)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 176485 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    Piggybac TetO - Blastocidin
  • Backbone size w/o insert (bp) 11000
  • Total vector size (bp) 9000
  • Modifications to backbone
    estimated sizes
  • Vector type
    Mammalian Expression
  • Selectable markers
    Blasticidin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Growth instructions
    The Wernig lab uses Stbl3 or JM109 for downstream applications.
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Nurr1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1797
  • Entrez Gene
    NR4A2 (a.k.a. HZF-3, IDLDP, NOT, NURR1, RNR1, TINUR)
  • Promoter TetO

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Mfe1 (unknown if destroyed)
  • 3′ cloning site PacI (unknown if destroyed)
  • 5′ sequencing primer CCTTGTGTTCAGGCGCAG
  • 3′ sequencing primer TTAGAAAGGTAAGGTGTC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Piggybac-TetO-hNurr1-blast was a gift from Marius Wernig (Addgene plasmid # 176485 ; http://n2t.net/addgene:176485 ; RRID:Addgene_176485)

  • For your References section:

    Efficient generation of dopaminergic induced neuronal cells with midbrain characteristics. Ng YH, Chanda S, Janas JA, Yang N, Kokubu Y, Sudhof TC, Wernig M. Stem Cell Reports. 2021 Jul 13;16(7):1763-1776. doi: 10.1016/j.stemcr.2021.05.017. Epub 2021 Jun 24. 10.1016/j.stemcr.2021.05.017 PubMed 34171286
