pGFP-EB1
(Plasmid #17234)

• Depositing Lab: Lynne Cassimeris
• Publication: Piehl et al Mol Biol Cell. 2003 Mar . 14(3):916-25.

Backbone

• Vector backbone: pEGFP-N1
• Backbone manufacturer: Clontech
• Backbone size w/o insert (bp): 4700
• Vector type: Mammalian Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Kanamycin, 50 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: EB1
• Species: H. sapiens (human)
• Insert Size (bp): 800
• GenBank ID: NM_012325
• Entrez Gene: MAPRE1 (a.k.a. EB1)
• Tag / Fusion Protein:
  • GFP (C terminal on backbone)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: SacI (not destroyed)
• 3′ cloning site: SmaI (not destroyed)
• 5′ sequencing primer: CMV-F
• 3′ sequencing primer: EGFP-N

Resource Information

• A portion of this plasmid was derived from a plasmid made by: Dr. David Pellman, DFCI, Boston, MA
• Articles Citing this Plasmid:
  • 18 References

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry
