pSpG-PPE
(Plasmid #170130)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 170130 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pUC
  • Vector type
    Plant Expression, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    nCas9-SpG(H840A)-M-MLV
  • Alt name
    NLS-nCas9-SpG(H840A)-NLS-32aa linker-M-MLV-NLS
  • Species
    M. musculus (mouse); Streptococcus pyogenes
  • Mutation
    H840A, D1135L, S1136W, G1218K, E1219Q, R1335Q, T1337R for Cas9; D200N, T306K, W313F, T330P and L603W for M-MLV
  • Promoter maize Ubiquitin-1

Cloning Information

  • Cloning method Gibson Cloning

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSpG-PPE was a gift from Caixia Gao (Addgene plasmid # 170130 ; http://n2t.net/addgene:170130 ; RRID:Addgene_170130)
  • For your References section:

    High-efficiency prime editing with optimized, paired pegRNAs in plants. Lin Q, Jin S, Zong Y, Yu H, Zhu Z, Liu G, Kou L, Wang Y, Qiu JL, Li J, Gao C. Nat Biotechnol. 2021 Mar 25. pii: 10.1038/s41587-021-00868-w. doi: 10.1038/s41587-021-00868-w. 10.1038/s41587-021-00868-w PubMed 33767395
