pMOS009: QuasAr2-mOrange2 voltage sensor (plasma membrane)
(Plasmid
#163043)
-
PurposeQuasAr2-mOrange2 voltage sensor (plasma membrane)
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 163043 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepLX304
- Backbone size w/o insert (bp) 9377
-
Vector typeMammalian Expression, Lentiviral
-
Selectable markersBlasticidin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature30°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameQuasAr2
-
SpeciesSynthetic
-
Insert Size (bp)1557
- Promoter CMV
-
Tag
/ Fusion Protein
- mOrange2 (C terminal on insert)
Cloning Information
- Cloning method Gateway Cloning
- 5′ sequencing primer CMV-F
- 3′ sequencing primer WPRE-R (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please see PMID: 24952910 for original reporter gene characterization.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pMOS009: QuasAr2-mOrange2 voltage sensor (plasma membrane) was a gift from Adam Cohen (Addgene plasmid # 163043 ; http://n2t.net/addgene:163043 ; RRID:Addgene_163043) -
For your References section:
Multiplexed Optical Sensors in Arrayed Islands of Cells for multimodal recordings of cellular physiology. Werley CA, Boccardo S, Rigamonti A, Hansson EM, Cohen AE. Nat Commun. 2020 Aug 4;11(1):3881. doi: 10.1038/s41467-020-17607-5. 10.1038/s41467-020-17607-5 PubMed 32753572
