pBbS8c-ddcpf1-rfp
(Plasmid
#153038)
-
PurposeFor CRISPRi. Arabinose-inducible ddcpf1 gene with CRISPR array targeting the mrfp reporter gene.
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 153038 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepBbS8c-RFP
- Total vector size (bp) 8762
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Chloramphenicol, 25 μg/mL
-
Growth Temperature30°C
-
Growth Strain(s)DH5alpha
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert nameAscpf1
-
SpeciesAcidaminococcus sp. BV3L6
-
Insert Size (bp)3921
-
MutationE993A
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pBbS8c-ddcpf1-rfp was a gift from Nigel Scrutton (Addgene plasmid # 153038 ; http://n2t.net/addgene:153038 ; RRID:Addgene_153038) -
For your References section:
A plasmid toolset for CRISPR-mediated genome editing and CRISPRi gene regulation in Escherichia coli. Jervis AJ, Hanko EKR, Dunstan MS, Robinson CJ, Takano E, Scrutton NS. Microb Biotechnol. 2021 Mar 12. doi: 10.1111/1751-7915.13780. 10.1111/1751-7915.13780 PubMed 33710766
