pcDNA3.1-N-Myc_DED/AAA USP7
(Plasmid #131253)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 131253 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1+/N-Myc
  • Backbone manufacturer
    Genscript
  • Backbone size w/o insert (bp) 5435
  • Total vector size (bp) 8756
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Ubiquitin carboxyl-terminal hydrolase 7
  • Alt name
    Ubiquitin-specific-processing protease 7
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    3321
  • Mutation
    Contains point mutations that convert USP7 aspartate 758, glutamate 759 and aspartate 764 to alanine (D758A_E759A_D764A), as well as introduces a silent KasI restriction site
  • Entrez Gene
    USP7 (a.k.a. C16DELp13.2, DEL16P13.2, HAFOUS, HAUSP, TEF1)
  • Tag / Fusion Protein
    • Myc (N terminal on backbone)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1-N-Myc_DED/AAA USP7 was a gift from Roger Woodgate (Addgene plasmid # 131253 ; http://n2t.net/addgene:131253 ; RRID:Addgene_131253)

  • For your References section:

    DNA Polymerase iota Interacts with Both the TRAF-like and UBL1-2 Domains of USP7. Ashton NW, Valles GJ, Jaiswal N, Bezsonova I, Woodgate R. J Mol Biol. 2021 Jan 22;433(2):166733. doi: 10.1016/j.jmb.2020.166733. Epub 2020 Dec 3. 10.1016/j.jmb.2020.166733 PubMed 33279577
