pAAV-CaMKII-SomArchon
(Plasmid #126942)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 126942 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pAAV-CaMKII
  • Backbone size w/o insert (bp) 4813
  • Total vector size (bp) 6634
  • Vector type
    Mammalian Expression, AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    SomArchon
  • Species
    Synthetic
  • Insert Size (bp)
    1821
  • Promoter CaMKII
  • Tag / Fusion Protein
    • GFP

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer cgggcaggcgagtggccc
  • 3′ sequencing primer CATAGCGTAAAAGGAGCAACA
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-CaMKII-SomArchon was a gift from Edward Boyden (Addgene plasmid # 126942 ; http://n2t.net/addgene:126942 ; RRID:Addgene_126942)
  • For your References section:

    Population imaging of neural activity in awake behaving mice. Piatkevich KD, Bensussen S, Tseng HA, Shroff SN, Lopez-Huerta VG, Park D, Jung EE, Shemesh OA, Straub C, Gritton HJ, Romano MF, Costa E, Sabatini BL, Fu Z, Boyden ES, Han X. Nature. 2019 Oct;574(7778):413-417. doi: 10.1038/s41586-019-1641-1. Epub 2019 Oct 9. 10.1038/s41586-019-1641-1 PubMed 31597963
