pARNTL.1.0-gDNA
(Plasmid #112480)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 112480 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pX330
  • Backbone manufacturer
    Zhang lab (Addgene plasmid ID: 42230)
  • Vector type
    Mammalian Expression, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    ARNTL
  • gRNA/shRNA sequence
    GTAAACACTACATGTTGCTT TGG
  • Species
    H. sapiens (human)
  • Entrez Gene
    BMAL1 (a.k.a. ARNTL, ARNTL1, BMAL1c, JAP3, MOP3, PASD3, TIC, bHLHe5)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BbsI (destroyed during cloning)
  • 3′ cloning site BbsI (destroyed during cloning)
  • 5′ sequencing primer hU6-F (5'-GAGGGCCTATTTCCCATGATT-3')
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

gRNA sequence listed includes 20 nucleotide target sequence, followed by the uncloned PAM sequence. The PAM sequence is not present in the plasmid. Use with plasmid pARNTL-donor.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pARNTL.1.0-gDNA was a gift from Kevin White (Addgene plasmid # 112480 ; http://n2t.net/addgene:112480 ; RRID:Addgene_112480)
