PurposeFluorescent fusion protein for tracking Akt signaling
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 67759 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backboneAddgene Plasmid: 17452
- Backbone size w/o insert (bp) 8679
- Total vector size (bp) 11358
-
Modifications to backboneReplaced CMV promoter with EF1a
-
Vector typeLentiviral
-
Selectable markersPuromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)Stbl3
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameFox01
-
Alt nameForkhead box protein O1
-
SpeciesM. musculus (mouse)
-
Insert Size (bp)2679
-
MutationChanged Serine 209 to Alanine, changed Histidine 212 to Arginine, changed Serine 215 to Alanine
-
Entrez GeneFoxo1 (a.k.a. Afxh, FKHR, Fkhr1, Foxo1a)
- Promoter EF1a
-
Tag
/ Fusion Protein
- Clover (C terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site Pac1 (not destroyed)
- 3′ cloning site Xba1 (not destroyed)
- 5′ sequencing primer EF1a-F
- 3′ sequencing primer WPRE-R (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made byFOXO1: Addgene Plasmid 34678 Clover: Addgene Plasmid 40259
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Note: Addgene's quality control sequencing finds four additional amino acid residue substitutions in the murine FoxO1 insert: Q275R, N515Y, S574N, and L619P. The depositing laboratory has tested this construct biochemically and determined that these residue changes do not detrimentally affect plasmid function.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pLenti-FoxO1-Clover was a gift from Peter Rotwein (Addgene plasmid # 67759 ; http://n2t.net/addgene:67759 ; RRID:Addgene_67759) -
For your References section:
Akt signaling dynamics in individual cells. Gross SM, Rotwein P. J Cell Sci. 2015 Jun 3. pii: jcs.168773. 10.1242/jcs.168773 PubMed 26040286
