pJZC40
(Plasmid #62334)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 62334 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    MP177_U6 (derived from pSico)
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Marked by mCherry

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    Stbl3
  • Copy number
    Unknown

Gene/Insert 1

  • Gene/Insert name
    sgRNA + 2x PP7
  • Mutation
    Targets Tet3G, sequence: GTACGTTCTCTATCACTGATA
  • Promoter U6

Cloning Information for Gene/Insert 1

Gene/Insert 2

  • Gene/Insert name
    mCherry
  • Promoter CMV

Cloning Information for Gene/Insert 2

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pJZC40 was a gift from Wendell Lim & Stanley Qi (Addgene plasmid # 62334 ; http://n2t.net/addgene:62334 ; RRID:Addgene_62334)

  • For your References section:

    Engineering Complex Synthetic Transcriptional Programs with CRISPR RNA Scaffolds. Zalatan JG, Lee ME, Almeida R, Gilbert LA, Whitehead EH, La Russa M, Tsai JC, Weissman JS, Dueber JE, Qi LS, Lim WA. Cell. 2014 Dec 18. pii: S0092-8674(14)01570-0. doi: 10.1016/j.cell.2014.11.052. 10.1016/j.cell.2014.11.052 PubMed 25533786
