pMK11-01
(Plasmid #99605)

• Purpose: Plasmid containing parBp-mKate2 fusion
• Depositing Labs: Morten Kjos, Jan-Willem Veening
• Publication: van Raaphorst et al Proc Natl Acad Sci U S A. 2017 Jul 3. pii: 201620608. doi: 10.1073/pnas.1620608114.

Backbone

• Vector backbone: pMK11
• Backbone size w/o insert (bp): 8003
• Total vector size (bp): 9544
• Vector type: Synthetic Biology

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: parBp-mKate2
• Insert Size (bp): 1541
• Promoter: PczcD
• Tag / Fusion Protein:
  • mKate2 (C terminal on insert)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: EcoRI (unknown if destroyed)
• 3′ cloning site: SpeI (unknown if destroyed)
• 5′ sequencing primer: CGAGTCTGGTGGTTGGTAAG
• 3′ sequencing primer: CGAAATACGGGCAGACATGG

Resource Information

• Supplemental Documents:
  • pMK11-parBp-mKate2 (pMK11-01).gbk
• Article Citing this Plasmid:
  • 1 Reference

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
  • Evrogen Limited Use Label License for FPs
• Industry Terms:
  • Not Available to Industry
