TMEM230-WT-DsRed(isoform 2)
(Plasmid #99563)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 99563 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pDsRed2-N1 (632406)
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4300
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    TMEM230
  • Alt name
    NM_001009924
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    368
  • Entrez Gene
    TMEM230 (a.k.a. C20orf30, HSPC274, dJ1116H23.2.1)
  • Promoter CMV
  • Tag / Fusion Protein
    • DsRed (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (unknown if destroyed)
  • 3′ cloning site BamHI (unknown if destroyed)
  • 5′ sequencing primer CMV-F
  • 3′ sequencing primer TCG CCG TCC AGC TCG ACC AGG AT
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    TMEM230-WT-DsRed(isoform 2) was a gift from Han-Xiang Deng (Addgene plasmid # 99563 ; http://n2t.net/addgene:99563 ; RRID:Addgene_99563)

  • For your References section:

    Identification of TMEM230 mutations in familial Parkinson's disease. Deng HX, Shi Y, Yang Y, Ahmeti KB, Miller N, Huang C, Cheng L, Zhai H, Deng S, Nuytemans K, Corbett NJ, Kim MJ, Deng H, Tang B, Yang Z, Xu Y, Chan P, Huang B, Gao XP, Song Z, Liu Z, Fecto F, Siddique N, Foroud T, Jankovic J, Ghetti B, Nicholson DA, Krainc D, Melen O, Vance JM, Pericak-Vance MA, Ma YC, Rajput AH, Siddique T. Nat Genet. 2016 Jul;48(7):733-9. doi: 10.1038/ng.3589. Epub 2016 Jun 6. 10.1038/ng.3589 PubMed 27270108
