pXY027
(Plasmid #98915)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 98915 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pCA24N
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Growth instructions
    Note the depositor uses BW25113 for molecular/imaging assays, as this strain provided a more “wild-type” background.
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    FtsZ
  • Species
    E. coli
  • Insert Size (bp)
    1149
  • Promoter T5-lac
  • Tag / Fusion Protein
    • GFP (C terminal on insert)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer ctttcgtcttcacctcgagaaatc
  • 3′ sequencing primer gctaattaagcttggctgcaggt
  • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    pCA24N-FtsZ-GFP from ASKA collection
  • Article Citing this Plasmid

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The His tag in N'-FtsZ was removed. 6bp were added between the RBS and start codon of FtsZ to decrease the expression level of FstZ-GFP.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pXY027 was a gift from Jie Xiao (Addgene plasmid # 98915 ; http://n2t.net/addgene:98915 ; RRID:Addgene_98915)
  • For your References section:

    A multi-layered protein network stabilizes the Escherichia coli FtsZ-ring and modulates constriction dynamics. Buss J, Coltharp C, Shtengel G, Yang X, Hess H, Xiao J. PLoS Genet. 2015 Apr 7;11(4):e1005128. doi: 10.1371/journal.pgen.1005128. eCollection 2015 Apr. PGENETICS-D-14-03238 [pii] PubMed 25848771
