pJB089
(Plasmid #98914)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 98914 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pCA24N
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert 1

  • Gene/Insert name
    FtsZ
  • Species
    E. coli
  • Insert Size (bp)
    1149
  • GenBank ID
    NC_000913.3
  • Promoter T5-lac
  • Tag / Fusion Protein
    • pAmCherry1 (C terminal on insert)

Cloning Information for Gene/Insert 1

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer AAGCGCATTCTGAGCTGCC
  • 3′ sequencing primer gctaattaagcttggctgcaggt
  • (Common Sequencing Primers)

Gene/Insert 2

  • Gene/Insert name
    ZapA
  • Species
    E. coli
  • Insert Size (bp)
    327
  • GenBank ID
    NC_000913.3
  • Promoter T5-lac
  • Tag / Fusion Protein
    • Dronpa (N terminal on insert)

Cloning Information for Gene/Insert 2

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer ctttcgtcttcacctcgagaaatc
  • 3′ sequencing primer CTTTAATCACCGCGTCATTGG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pJB089 was a gift from Jie Xiao (Addgene plasmid # 98914 ; http://n2t.net/addgene:98914 ; RRID:Addgene_98914)
  • For your References section:

    A multi-layered protein network stabilizes the Escherichia coli FtsZ-ring and modulates constriction dynamics. Buss J, Coltharp C, Shtengel G, Yang X, Hess H, Xiao J. PLoS Genet. 2015 Apr 7;11(4):e1005128. doi: 10.1371/journal.pgen.1005128. eCollection 2015 Apr. PGENETICS-D-14-03238 [pii] PubMed 25848771
