pSNAPf-Nup43
(Plasmid #98276)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 98276 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    plasmid PAtagRFP-actin (Verkhusha lab/Addgene)
  • Backbone manufacturer
    Clontech
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Nup43
  • Species
    H. sapiens (human)
  • Entrez Gene
    NUP43 (a.k.a. bA350J20.1, p42)
  • Promoter CMV
  • Tag / Fusion Protein
    • SNAPf-tag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)
  • 3′ cloning site unknown (unknown if destroyed)
  • 5′ sequencing primer CMV-F
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSNAPf-Nup43 was a gift from Mike Heilemann (Addgene plasmid # 98276 ; http://n2t.net/addgene:98276 ; RRID:Addgene_98276)

  • For your References section:

    A set of homo-oligomeric standards allows accurate protein counting. Finan K, Raulf A, Heilemann M. Angew Chem Int Ed Engl. 2015 Oct 5;54(41):12049-52. doi: 10.1002/anie.201505664. Epub 2015 Aug 20. 10.1002/anie.201505664 PubMed 26289028
