pcDNA3.1 CMV mCherry-eGFP BGH
(Plasmid #92280)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 92280 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone manufacturer
    Invitrogen
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    mCherry-eGFP
  • Species
    Synthetic
  • Insert Size (bp)
    1485
  • Promoter CMV

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer GAGAACCCACTGCTTACTGGC
  • 3′ sequencing primer TAGAAGGCACAGTCGAGG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1 CMV mCherry-eGFP BGH was a gift from Baljit Khakh (Addgene plasmid # 92280 ; http://n2t.net/addgene:92280 ; RRID:Addgene_92280)

  • For your References section:

    An Optical Neuron-Astrocyte Proximity Assay at Synaptic Distance Scales. Octeau JC, Chai H, Jiang R, Bonanno SL, Martin KC, Khakh BS. Neuron. 2018 Apr 4;98(1):49-66.e9. doi: 10.1016/j.neuron.2018.03.003. 10.1016/j.neuron.2018.03.003 PubMed 29621490
