pSB1A3_GFP_dT17
(Plasmid #89660)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 89660 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pSB1A3
  • Backbone manufacturer
    igem parts registry
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    GFP_dT17
  • Species
    Synthetic
  • Insert Size (bp)
    6000
  • Promoter T7
  • Tag / Fusion Protein
    • His6 (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)
  • 3′ cloning site unknown (unknown if destroyed)
  • 5′ sequencing primer attaccgcctttgagtgagc
  • 3′ sequencing primer tgccacctgacgtctaagaa
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSB1A3_GFP_dT17 was a gift from Hendrik Dietz (Addgene plasmid # 89660 ; http://n2t.net/addgene:89660 ; RRID:Addgene_89660)

  • For your References section:

    Self-assembly of genetically encoded DNA-protein hybrid nanoscale shapes. Praetorius F, Dietz H. Science. 2017 Mar 24;355(6331). pii: eaam5488. doi: 10.1126/science.aam5488. 10.1126/science.aam5488 PubMed 28336611
Related items:
Commonly requested with:
