Addgene

Green cGull
(Plasmid #86867)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 86867 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA3.1 (-)
  • Backbone size w/o insert (bp) 5358
  • Total vector size (bp) 6494
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Green cGull
  • Insert Size (bp)
    1135
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site HindIII (not destroyed)
  • 5′ sequencing primer CMV-Forward, 5'-CGC AAA TGG GCG GTA GGC GTG-3'
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Green cGull was a gift from Tetsuya Kitaguchi (Addgene plasmid # 86867 ; http://n2t.net/addgene:86867 ; RRID:Addgene_86867)
  • For your References section:

    Generation of a cGMP Indicator with an Expanded Dynamic Range by Optimization of Amino Acid Linkers between a Fluorescent Protein and PDE5alpha. Matsuda S, Harada K, Ito M, Takizawa M, Wongso D, Tsuboi T, Kitaguchi T. ACS Sens. 2017 Jan 27;2(1):46-51. doi: 10.1021/acssensors.6b00582. Epub 2016 Dec 29. 10.1021/acssensors.6b00582 PubMed 28722423
