pFBD-Btk(PH)Akt1(KD)
(Plasmid #86591)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 86591 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pFastBac Dual
  • Total vector size (bp) 1602
  • Vector type
    Insect Expression
  • Selectable markers
    Gentamicin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PH(Btk)-KD(Akt1) fusion
  • Species
    H. sapiens (human)
  • Entrez Gene
    AKT1 (a.k.a. AKT, PKB, PKB-ALPHA, PRKBA, RAC, RAC-ALPHA)
  • Entrez Gene
    BTK (a.k.a. AGMX1, AT, ATK, BPK, IGHD3, IMD1, PSCTK1, XLA)
  • Tag / Fusion Protein
    • 10xHis (N terminal on insert)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Cloned by Iva LUCIC

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pFBD-Btk(PH)Akt1(KD) was a gift from Thomas Leonard & Ivan Yudushkin (Addgene plasmid # 86591 ; http://n2t.net/addgene:86591 ; RRID:Addgene_86591)
  • For your References section:

    PI(3,4,5)P3 Engagement Restricts Akt Activity to Cellular Membranes. Ebner M, Lucic I, Leonard TA, Yudushkin I. Mol Cell. 2017 Feb 2;65(3):416-431.e6. doi: 10.1016/j.molcel.2016.12.028. 10.1016/j.molcel.2016.12.028 PubMed 28157504
