pCMV-GCaMP6fu
(Plasmid #86235)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 86235 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pEGFP-N1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3945
  • Total vector size (bp) 5308
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    GCaMP6fu
  • Species
    R. norvegicus (rat); A. victoria (jellyfish)
  • Insert Size (bp)
    1323
  • Mutation
    W43Y D395A
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BglII (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer EGFP-N
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    A portion of this plasmid was derived from a plasmid made by Douglas Kim

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCMV-GCaMP6fu was a gift from Katalin Torok (Addgene plasmid # 86235 ; http://n2t.net/addgene:86235 ; RRID:Addgene_86235)
  • For your References section:

    Design and mechanistic insight into ultrafast calcium indicators for monitoring intracellular calcium dynamics. Helassa N, Podor B, Fine A, Torok K. Sci Rep. 2016 Dec 6;6:38276. doi: 10.1038/srep38276. 10.1038/srep38276 PubMed 27922063
