pEJS481-pCDest2-AcrE2-mTagBFP2-IRES
(Plasmid
#85749)
-
PurposeExpresses anti-CRISPR protein from Type I-E and mTagBFP2
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 85749 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCSDest2
- Total vector size (bp) 7119
-
Vector typeMammalian Expression, CRISPR
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert 1
-
Gene/Insert nameType I-E anti-CRISPR
-
SpeciesPseudomonas aeruginosa
-
Insert Size (bp)252
- Promoter CMV
Cloning Information for Gene/Insert 1
- Cloning method Gibson Cloning
- 5′ sequencing primer ATTTAGGTGACACTATAGA (Common Sequencing Primers)
Gene/Insert 2
-
Gene/Insert namemTagBFP2
-
SpeciesSynthetic
-
Insert Size (bp)711
- Promoter CMV
Cloning Information for Gene/Insert 2
- Cloning method Gibson Cloning
- 5′ sequencing primer CGC AAA TGG GCG GTA GGC GTG
- 3′ sequencing primer CAG GAA ACA GCT ATG AC (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
A portion of this plasmid was derived from a plasmid made bypIRES-mTagBFP2 is a gift from David Grünwald. Type I-E anti-CRISPR protein (AcrE2) is described by Pawluk et al. (2014).
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Pawluk, A., Bondy-Denomy, J., Cheung, V.H., Maxwell, K.L., and Davidson, A.R. (2014). A new group of phage anti-CRISPR genes inhibits the type I-E CRISPR-Cas system of Pseudomonas aeruginosa. MBio 5, e00896.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pEJS481-pCDest2-AcrE2-mTagBFP2-IRES was a gift from Erik Sontheimer (Addgene plasmid # 85749 ; http://n2t.net/addgene:85749 ; RRID:Addgene_85749) -
For your References section:
Naturally Occurring Off-Switches for CRISPR-Cas9. Pawluk A, Amrani N, Zhang Y, Garcia B, Hidalgo-Reyes Y, Lee J, Edraki A, Shah M, Sontheimer EJ, Maxwell KL, Davidson AR. Cell. 2016 Dec 15;167(7):1829-1838.e9. doi: 10.1016/j.cell.2016.11.017. Epub 2016 Dec 8. 10.1016/j.cell.2016.11.017 PubMed 27984730
