pBK-YEE-BE3
(Plasmid #85177)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 85177 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    CMV
  • Backbone manufacturer
    origene
  • Backbone size w/o insert (bp) 3399
  • Total vector size (bp) 8532
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    YEE-BE3
  • Alt name
    rAPOBEC1(W90Y/R126E/R132E)-XTEN-Cas9n-UGI-NLS
  • Species
    R. norvegicus (rat); S. pyogenes
  • Insert Size (bp)
    5133
  • Promoter CMV

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer CMV
  • 3′ sequencing primer TGGTTCTTTCCGCCTCAGAAGC
  • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Cloned from Addgene #73021
  • Article Citing this Plasmid

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBK-YEE-BE3 was a gift from David Liu (Addgene plasmid # 85177 ; http://n2t.net/addgene:85177 ; RRID:Addgene_85177)
  • For your References section:

    Increasing the genome-targeting scope and precision of base editing with engineered Cas9-cytidine deaminase fusions. Kim YB, Komor AC, Levy JM, Packer MS, Zhao KT, Liu DR. Nat Biotechnol. 2017 Feb 13. doi: 10.1038/nbt.3803. 10.1038/nbt.3803 PubMed 28191901
