PurposeExpresses human codon-optimized AsCpf1 protein and blasticidin resistance from EFS promoter. Lentiviral backbone.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 84750 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonelentiCas9-Blast(Addgene#:52962)
- Backbone size w/o insert (bp) 8700
- Total vector size (bp) 12670
-
Vector typeMammalian Expression, Lentiviral, CRISPR
-
Selectable markersBlasticidin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Growth instructionsUse SapI digest to check for unwanted recombination of lentiviral plasmid. Only amplify in RecA- bacteria (eg. Stbl3).
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameAsCpf1
-
Alt nameCpf1
-
Alt nameAsCas12a
-
SpeciesAcidaminococcus_sp_BV3L6
-
Insert Size (bp)3970
- Promoter EFS-NS
-
Tag
/ Fusion Protein
- NLS-3xHA (C terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site AgeI (not destroyed)
- 3′ cloning site BamHI (not destroyed)
- 5′ sequencing primer pLLU-F (5'-gggacagcagagatccagtt-3')
- 3′ sequencing primer blast-R (5'-gctctttcaatgagggtgga-3') (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
Lenti-AsCpf1-Blast was a gift from Hyongbum Kim (Addgene plasmid # 84750 ; http://n2t.net/addgene:84750 ; RRID:Addgene_84750) -
For your References section:
In vivo high-throughput profiling of CRISPR-Cpf1 activity. Kim HK, Song M, Lee J, Menon AV, Jung S, Kang YM, Choi JW, Woo E, Koh HC, Nam JW, Kim H. Nat Methods. 2016 Dec 19. doi: 10.1038/nmeth.4104. 10.1038/nmeth.4104 PubMed 27992409
