pNCS-CyRFP1
(Plasmid #84546)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 84546 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pNCS
  • Backbone size w/o insert (bp) 2834
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CyRFP1
  • Insert Size (bp)
    702
  • Tag / Fusion Protein
    • His (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer T7
  • 3′ sequencing primer T7term
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pNCS-CyRFP1 was a gift from Michael Lin (Addgene plasmid # 84546 ; http://n2t.net/addgene:84546 ; RRID:Addgene_84546)

  • For your References section:

    Simultaneous dual-color fluorescence lifetime imaging with novel red-shifted fluorescent proteins. Laviv T, Kim BB, Chu J, Lam AJ, Lin MZ, Yasuda R. Nat Methods. 2016 Oct 31. doi: 10.1038/nmeth.4046. 10.1038/nmeth.4046 PubMed 27798609
