mCyRFP1-C1
(Plasmid #84355)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 84355 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    EGFP-C1
  • Backbone size w/o insert (bp) 4000
  • Total vector size (bp) 4700
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    mCyRFP1
  • Species
    Synthetic
  • Insert Size (bp)
    702
  • Mutation
    A161K and N41A, reletive to CyRFP1
  • Promoter CMV

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer CGCAAATGGGCGGTAGGCG
  • 3′ sequencing primer ATGATCAGTTATCTAGATCCG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    mCyRFP1-C1 was a gift from Ryohei Yasuda (Addgene plasmid # 84355 ; http://n2t.net/addgene:84355 ; RRID:Addgene_84355)

  • For your References section:

    Simultaneous dual-color fluorescence lifetime imaging with novel red-shifted fluorescent proteins. Laviv T, Kim BB, Chu J, Lam AJ, Lin MZ, Yasuda R. Nat Methods. 2016 Oct 31. doi: 10.1038/nmeth.4046. 10.1038/nmeth.4046 PubMed 27798609
