CyRFP1-C1
(Plasmid
#84354)
-
PurposeExpresses CyRFP1 fluorescent protein in an empty backbone
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 84354 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backboneEGFP-C1
- Backbone size w/o insert (bp) 4000
- Total vector size (bp) 4724
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameCyRFP1
-
SpeciesSynthetic
-
Insert Size (bp)702
-
MutationH61M (compared with CyOFP)
- Promoter CMV
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer cggtgggaggtctatataagc
- 3′ sequencing primer TGATCAGTTATCTAGATCCG (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
CyRFP1-C1 was a gift from Ryohei Yasuda (Addgene plasmid # 84354 ; http://n2t.net/addgene:84354 ; RRID:Addgene_84354) -
For your References section:
Simultaneous dual-color fluorescence lifetime imaging with novel red-shifted fluorescent proteins. Laviv T, Kim BB, Chu J, Lam AJ, Lin MZ, Yasuda R. Nat Methods. 2016 Oct 31. doi: 10.1038/nmeth.4046. 10.1038/nmeth.4046 PubMed 27798609
