PurposeFluorescent probe for S/G2 cell cycle transition
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 83914 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepLL3.7m
- Backbone size w/o insert (bp) 6500
- Total vector size (bp) 7426
-
Vector typeMammalian Expression, Lentiviral
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namemKO2-SLBP(18-126)
-
SpeciesH. sapiens (human), Synthetic
-
Insert Size (bp)1035
-
Entrez GeneSLBP (a.k.a. HBP)
- Promoter CMV
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site NheI (not destroyed)
- 3′ cloning site EcoRI (not destroyed)
- 5′ sequencing primer agctggtttagtgaaccgtcagatc
- 3′ sequencing primer ggaaccggaacccttaaaca (Common Sequencing Primers)
Resource Information
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
mKO2-SLBP(18-126) was a gift from Michael Lin (Addgene plasmid # 83914 ; http://n2t.net/addgene:83914 ; RRID:Addgene_83914) -
For your References section:
Fluorescent indicators for simultaneous reporting of all four cell cycle phases. Bajar BT, Lam AJ, Badiee RK, Oh YH, Chu J, Zhou XX, Kim N, Kim BB, Chung M, Yablonovitch AL, Cruz BF, Kulalert K, Tao JJ, Meyer T, Su XD, Lin MZ. Nat Methods. 2016 Oct 31. doi: 10.1038/nmeth.4045. 10.1038/nmeth.4045 PubMed 27798610
