pBS7
(Plasmid #83774)

• Purpose: Useful for tagging yeast proteins with C-terminal Venus tag; G418 selection
• Depositing Lab: Eric Muller
• Publication: Hailey et al Methods Enzymol. 2002;351:34-49.

Backbone

• Vector backbone: pDH6
• Backbone manufacturer: Muller Lab, Addgene plasmid 83777
• Vector type: Yeast Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: Unknown

Gene/Insert

• Gene/Insert name: Venus
• Mutation: F46L, F64L, S65G, V68L, Q69M, S72A, Q80R, M153T, V163A, S175G, T203Y *Q80R is believed to be a neutral mutation.

Cloning Information

• Cloning method: Unknown
• 5′ sequencing primer: SP6

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Depositor Comments

For more information, see http://yeastrc.org/yeastrc/pages/plasmids_protocols.html

Plasmid pBS7 is built from pDH6 except YFP has been mutated to the Venus variant. Those mutations are described in "A variant of yellow fluorescent protein with fast and efficient maturation for cell-biological applications" by Nagai, Ibata, Park, Kubota, Mikoshiba and Miyawaki in Nat Biotechnol 2002 Jan;20(1):87-90. In addition we have included Q69M, a mutation briefly mentioned in the Nagai et al. paper as potentially beneficial, although not necessary for the enhanced maturation.
