pPHAGE_DLD-H450A-C-TAP
(Plasmid #83478)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 83478 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pPHAGE C-TAP
  • Backbone manufacturer
    PMID: 26186194
  • Backbone size w/o insert (bp) 10056
  • Total vector size (bp) 9368
  • Modifications to backbone
    Partial removal of gateway cassette.
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    DLD
  • Alt name
    Dihydrolipoamide Dehydrogenase
  • Species
    H. sapiens (human)
  • Mutation
    H450A
  • GenBank ID
    NM_000108.4
  • Entrez Gene
    DLD (a.k.a. DLDD, DLDH, E3, GCSL, LAD, OGDC-E3, PHE3)
  • Promoter CMV
  • Tag / Fusion Protein
    • TAP (C terminal on insert)

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ sequencing primer CMV_F, mutation confirmation (CTCTTGGTTTGCATTGGCCG)
  • 3′ sequencing primer IRES_R
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    The plasmid was originally developed by authors of the paper PMID: 26186194.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Mutation (first described in PMID: 17404228) was created using the method described in PMID: 17446874. Two outer (F: CTCTTGGTTTGCATTGGCCG, IRES_R: CCTCACATTGCCAAAAGACG) and two mutation-site primers were used. The mutated PCR product and the backbone vector were digested using EcoRI, gel purified and ligated.

Note that the mutation is numbered in accordance with the original publication (PMID: 17404228), which lacked the mitochondrial targeting signal (residues 1-35). In this full-length protein, it is found at position 485.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pPHAGE_DLD-H450A-C-TAP was a gift from Mohan Babu (Addgene plasmid # 83478 ; http://n2t.net/addgene:83478 ; RRID:Addgene_83478)
  • For your References section:

    A Map of Human Mitochondrial Protein Interactions Linked to Neurodegeneration Reveals New Mechanisms of Redox Homeostasis and NF-kappaB Signaling. Malty RH, Aoki H, Kumar A, Phanse S, Amin S, Zhang Q, Minic Z, Goebels F, Musso G, Wu Z, Abou-Tok H, Meyer M, Deineko V, Kassir S, Sidhu V, Jessulat M, Scott NE, Xiong X, Vlasblom J, Prasad B, Foster LJ, Alberio T, Garavaglia B, Yu H, Bader GD, Nakamura K, Parkinson J, Babu M. Cell Syst. 2017 Nov 7. pii: S2405-4712(17)30447-7. doi: 10.1016/j.cels.2017.10.010. 10.1016/j.cels.2017.10.010 PubMed 29128334
