pTRIPZ (M)-HT-Cbx7-Delta-ATL
(Plasmid #82523)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 82523 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pTRIPZ (M)
  • Backbone size w/o insert (bp) 1300
  • Total vector size (bp) 13814
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Chromobox Homolog 7
  • Alt name
    Cbx7
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    702
  • Mutation
    deletion of amino acids 66–83
  • GenBank ID
    NM_175709
  • Entrez Gene
    CBX7
  • Promoter CMV
  • Tag / Fusion Protein
    • HaloTag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoR1 (unknown if destroyed)
  • 3′ cloning site Mlu1 (unknown if destroyed)
  • 5′ sequencing primer CCGATCAGGTCCGGGTTGTCTT
  • 3′ sequencing primer ctcacggcgagcgctgccacgtc
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTRIPZ (M)-HT-Cbx7-Delta-ATL was a gift from Xiaojun Ren (Addgene plasmid # 82523 ; http://n2t.net/addgene:82523 ; RRID:Addgene_82523)
