pLenti6-DCX-EGFP
(Plasmid #80599)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 80599 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pLenti6/V5-DEST
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 8500
  • Total vector size (bp) 9019
  • Vector type
    Lentiviral
  • Selectable markers
    Blasticidin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    Stbl3
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Doublecortin
  • Alt name
    DCX
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1095
  • GenBank ID
    NM_178152
  • Entrez Gene
    DCX (a.k.a. DBCN, DC, LISX, SCLH, XLIS)
  • Promoter CMV
  • Tag / Fusion Protein
    • EGFP (C terminal on insert)

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ sequencing primer CMV forward (CGCAAATGGGCGGTAGGCGTG)
  • 3′ sequencing primer EGFP N reverse (cgtcgccgtccagctcgaccag)
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    The original DCX sequence comes from Addgene Plasmid #32851
  • Article Citing this Plasmid

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLenti6-DCX-EGFP was a gift from Torsten Wittmann (Addgene plasmid # 80599 ; http://n2t.net/addgene:80599 ; RRID:Addgene_80599)
  • For your References section:

    Doublecortin Is Excluded from Growing Microtubule Ends and Recognizes the GDP-Microtubule Lattice. Ettinger A, van Haren J, Ribeiro SA, Wittmann T. Curr Biol. 2016 Jun 20;26(12):1549-55. doi: 10.1016/j.cub.2016.04.020. Epub 2016 May 26. 10.1016/j.cub.2016.04.020 PubMed 27238282
