pcDNA3.1_pCMV-dCas-PmCDA1-ugi pH1-gRNA(HPRT)
(Plasmid #79622)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 79622 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5428
  • Total vector size (bp) 10414
  • Modifications to backbone
    Neomycin marker is connected to insert via 2A peptide
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    SpCas9
  • Species
    Streptococcus pyogenes
  • Mutation
    D10A and H840A for nuclease deficient dCas9
  • Promoter pCMV
  • Tags / Fusion Proteins
    • PmCDA1 (C terminal on insert)
    • UGI (C terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer ttcgctattacgccagctg
  • 3′ sequencing primer GACAGGTCGGTCTTGACA
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1_pCMV-dCas-PmCDA1-ugi pH1-gRNA(HPRT) was a gift from Akihiko Kondo (Addgene plasmid # 79622)

  • For your References section:

    Targeted nucleotide editing using hybrid prokaryotic and vertebrate adaptive immune systems. Nishida K, Arazoe T, Yachie N, Banno S, Kakimoto M, Tabata M, Mochizuki M, Miyabe A, Araki M, Hara KY, Shimatani Z, Kondo A. Science. 2016 Aug 4. pii: aaf8729. 10.1126/science.aaf8729 PubMed 27492474
