5E26 (PANK2)
(Plasmid #79516)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 79516 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pFBOH-MHL
  • Backbone manufacturer
    SGC (Addgene plasmid #62304)
  • Backbone size w/o insert (bp) 6767
  • Vector type
    Baculovirus Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PANK2
  • Alt name
    PANK2:PBC007-A01:C235806
  • Alt name
    PANK2:R205-K568
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1092
  • Entrez Gene
    PANK2 (a.k.a. C20orf48, HARP, HSS, NBIA1, PKAN)
  • Promoter polyhedrin
  • Tags / Fusion Proteins
    • 6xHis (N terminal on backbone)
    • TEV cleavage site (N terminal on backbone)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer pFBOH-fwd (5'-CCGGATTATTCATACCGTCCCACCA-3')
  • 3′ sequencing primer pFBOH-rev (5'-CTGATTATGATCCTCTAGTACTTCT-3')
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please see http://www.thesgc.org/structures/5E26 for more information.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    5E26 (PANK2) was a gift from Cheryl Arrowsmith (Addgene plasmid # 79516 ; http://n2t.net/addgene:79516 ; RRID:Addgene_79516)
