PHR-LAT Y6F YFFF-mCitrine (XSB589)
(Plasmid #78517)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 78517 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pHR
  • Total vector size (bp) 10400
  • Vector type
    Mammalian Expression, Lentiviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    LAT
  • Species
    H. sapiens (human)
  • Entrez Gene
    LAT (a.k.a. IMD52, LAT1, pp36)
  • Tag / Fusion Protein
    • mCitrine (C terminal on insert)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PHR-LAT Y6F YFFF-mCitrine (XSB589) was a gift from Ron Vale (Addgene plasmid # 78517 ; http://n2t.net/addgene:78517 ; RRID:Addgene_78517)

  • For your References section:

    Phase separation of signaling molecules promotes T cell receptor signal transduction. Su X, Ditlev JA, Hui E, Xing W, Banjade S, Okrut J, King DS, Taunton J, Rosen MK, Vale RD. Science. 2016 Apr 29;352(6285):595-9. doi: 10.1126/science.aad9964. Epub 2016 Apr 7. 10.1126/science.aad9964 PubMed 27056844
