N4BP2 gRNA (BRDN0001146056)
(Plasmid
#76338)
-
Purpose3rd generation lentiviral gRNA plasmid targeting human N4BP2
-
Depositing Labs
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 76338 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonelentiGuide-Puro
-
Backbone manufacturerZhang Lab (Addgene plasmid # 52963)
-
Vector typeMammalian Expression, Lentiviral, CRISPR
-
Selectable markersPuromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameN4BP2
-
Alt nameN4BP2
-
gRNA/shRNA sequenceGTTGTGTGCATATTCTTGTG
-
SpeciesH. sapiens (human)
-
Entrez GeneN4BP2 (a.k.a. B3BP)
- Promoter hU6
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer U6-F
- 3′ sequencing primer pS2-R (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
The gRNA was designed to target a Genbank reference sequence which has since been removed from the database. Note that this plasmid does NOT contain Cas9. It should be used in conjunction with lentiCas9-Blast (Addgene #52962) or otherwise with cell lines already expressing Cas9. Browse the full kinome gRNA library at http://www.addgene.org/pooled-library/broadgpp-human-kinome/ or visit http://www.broadinstitute.org/rnai/public/ for detailed protocols and information.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
N4BP2 gRNA (BRDN0001146056) was a gift from John Doench & David Root (Addgene plasmid # 76338 ; http://n2t.net/addgene:76338 ; RRID:Addgene_76338) -
For your References section:
Optimized sgRNA design to maximize activity and minimize off-target effects of CRISPR-Cas9. Doench JG, Fusi N, Sullender M, Hegde M, Vaimberg EW, Donovan KF, Smith I, Tothova Z, Wilen C, Orchard R, Virgin HW, Listgarten J, Root DE. Nat Biotechnol. 2016 Jan 18. doi: 10.1038/nbt.3437. 10.1038/nbt.3437 PubMed 26780180
