pOIMars1CyN
(Plasmid #75221)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 75221 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEGFP
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3958
  • Total vector size (bp) 5011
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    ss-HA-Mars1Cy-CD80(237-306)
  • Alt name
    ss-HA-dL9.5-CD80(237-306)
  • Species
    Synthetic
  • Insert Size (bp)
    1053
  • Promoter CMV
  • Tag / Fusion Protein
    • HA epitope (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site XmaI (not destroyed)
  • 5′ sequencing primer cgcaaatgggcggtaggcgtg
  • 3′ sequencing primer ctctacaaatgtggtatggctg
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pOIMars1CyN was a gift from Alan Waggoner (Addgene plasmid # 75221 ; http://n2t.net/addgene:75221 ; RRID:Addgene_75221)

  • For your References section:

    Fluoromodule-based reporter/probes designed for in vivo fluorescence imaging. Zhang M, Chakraborty SK, Sampath P, Rojas JJ, Hou W, Saurabh S, Thorne SH, Bruchez MP, Waggoner AS. J Clin Invest. 2015 Oct 1;125(10):3915-27. doi: 10.1172/JCI81086. Epub 2015 Sep 8. 10.1172/JCI81086 PubMed 26348895
